Rotary Torque sensors

https://korean-electronics.com//inquiry[INQ. NO. 2004E07] Model TRB load cell measures the torque of continuous rotation objects. The platinum-coated connector provides long-term signal stability and high accuracy. This model is most appropriate for industrial measurements.
Applications include the performance testers for automotive components such as clutches, transmissions, motors and pumps.
The TRS socket wrench torque sensor is used for fast, accurate measurement of bolt or nut wrenching torque. This model operates in both directions, so tightening and break-away torques can be measured. It can also be used to check the calibration of mechanical torque wrenches.

Dacell supplies ultra-precision load cells and various weighing and measuring products, which can be used in various fields of industries, based upon 20 years of experience in these areas applying its own superior technologies.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Two Ports Serial Communication Cards

https://korean-electronics.com//inquiry[INQ. NO. 2004E06] Multi-2/PCI is equipped with the powerful semiconductor of SystemBase – SB16C1052PCI, to deliver maximum performance of up to 921.6Kbps with the world’s leading 256 byte FIFO preventing overrun errors. Combine that with the need for fewer components and you get cost-effective and reliable connections to your serial devices.
Multiport boards support most Windows and Linux operating systems and include 15,000 volt





surge suppression, thus eliminating blown ports. Multi-2/PCI has two on-board DB9 connectors and is available in two models, RS232 and RS422/RS485 (COMBO). These boards are ideal for POS, hospitality, factory automation, and building automation applications.
Multi-2/PCI is configurable to deliver +5 or +12 volt power to pin-9 to power external devices. This functionality is ideal for connecting low-power devices such as barcode readers and receipt printers, eliminating the need for an external power supply.
Multi-2/PCI is equipped with slew rate limit control and when enabled it minimizes EMI emissions which may cause data transmission errors. When slew rate is used, the maximum communication speed is 250kbps. This functionality is recommended for many medical applications.





korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Resistive RH Sensor Module

https://korean-electronics.com//inquiry[INQ. NO. 2004E05] SY-HS-25 series, a resistive humidity sensor, is composed of a very durable resistive sensor and a thermistor for temperature compensation and offers cost-competitiveness and convenience for humidity measurement.
This module uses specially consolidated polymer and is designed for industrial environments that include both temperature environment (-20~85˚C) and humidity environment with dew condensation and gases. In addition, it can be used without calibration so that replacement of the sensor is easy and convenient.

Dew Sensor

SY-DS-1 Series, dew sensor, is a resistive type sensor which detects condensation risk in advance. The sensor only responds to high humidity environments regardless of temperature environment, and it is a switch-type sensor with an impedance value that changes abruptly in a high humidity environment.
It has an excellent reaction rate, no temperature dependence, and is water resistant, easy to implement, and simple to use. Two types of the product are available upon request.

Resistive RH Sensor

The industrial-grade, resistance-type humidity sensor, SYH-2R, offers cost-effective and convenient humidity measurement.
While maintaining the attractive features such as no-calibration requirement and high interchangeability of a resistive-type humidity sensor: SYH-1, SYH-2R widens the scope of applications to home appliances, HVAC, and automobiles.
Coated with patented polymer, SYH-2R can be used in demanding environments (-20°C~85°C) with frequent condensing and chemical vapors.
SYH-2R can be directly connected to µ-com with ADC or RFC converting resistance changes to either voltage or frequency. It can also be modularized to voltage output with oscillator.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Particle Sensors

https://korean-electronics.com//inquiry[INQ. NO. 2004E04] PSMU Series, incorporating 20 years of knowledge and technology of SAMYOUNG S&C, is a PM2.5 dedicated sensor with radical improvement for detection capability in the ultra-fine particle range – 0.3µm~1.0µm, which assures PM2.5 weight concentration values more accurate than conventional presumptive sensors.
PSMU Series, which performs higher accuracy along with improved sensitivity compared with conventional sensors, provides reliable information to users. This enables more accurate and sophisticated control in applications such as air purifiers, air conditioners, and air-quality measuring devices.
SAMYOUNG S&C has developed a system to reliably mass-produce PSMU Series of uniform performance through a mass calibration technology that also contributes to efficient production. Moreover, the patented aerodynamic optical structure maximizes the performance of the sensor, improving the quality of the product. In addition, it provides real-time PM2.5 weight concentration values in UART output for user convenience.
PSML Series, incorporating 20 years of knowledge, expertise and technology of SAMYOUNG S&C. is a PM2.5 dedicated sensor with a radical improvement for detection capability at ultra-fine particle range – 0.3µm~1.0µm, which enables classifying PM2.5 level more precise than existing sensors.
PSML Series – which performs higher accuracy, along with improved sensitivity, than conventional sensors – provides reliable information to users, thus enabling more accurate and sophisticated control in the applications such as air purifiers, air conditioners and air-quality measuring devices.
SAMYOUNG S&C has developed a system to reliably mass-produce the PSML Series with uniform performance through mass calibration technology that also ensures efficient production.
Moreover, the patented aerodynamic optical structure maximizes the performance of the sensor and improves the quality of the product.
In addition, it is designed to be pin-to-pin compatible with existing sensors for user convenience.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Humidity and Temperature Sensing Solutions

https://korean-electronics.com//inquiryHumiChip®

[INQ. NO. 2004E03] HumiChip® offers the most advanced and cost-effective humidity and temperature-sensing solution for virtually any type of application.
The capacitive polymer sensor chip developed and fabricated in-house, and CMOS integrated circuit with EEPROM are integrated into one embedded system in a reflow solder-able SMD package.
Individually calibrated and tested, HumiChip® performs ±2% from 20% to 80%RH (±3% over the entire humidity range), and yet it is simple and ready to use without further calibration or temperature compensation.
HumiChip® provides linear output signals in various interfaces according to customer requirements – including the standard I²C interface, and PDM convertible to analog signal.
Designed and manufactured by industry-leading humidity and temperature-sensing technology of SAMYOUNG S&C – it is field proven in the HVAC and auto industry for over 10 years, HumiChip® offers another smart sensing solution for excellent reliability, high accuracy, and cost-effective sensing applications.
HumiChip® applies newly developed polymer of SAMYOUNG S&C, so it offers outstanding performance in sub-zero temperature and hot environments. HumiChip® is AEC-Q100 qualified and become more applicable to various industries as an all-round polymer.

HCS2D-3V

HCS2D-3V is a single in-line package type of HCS2D-3V with a ready-installed V-Core capacitor for easy and convenient application.
HCS2D-3V is an improved version of HumiChip®, the most advanced and cost-effective humidity and temperature sensing solution for virtually any type of applications.
The capacitive polymer sensor chip developed and fabricated in-house and CMOS integrated circuit with EEPROM are integrated into one embedded system in a reflow solder-able SMD package.
Individually calibrated and tested, HCS2D-3V performs ±2% from 20% to 80%RH (±4% over the entire humidity range), and yet, is simple and ready to use without further calibration or temperature compensation.
Designed and manufactured by industry-leading humidity and temperature-sensing technology of SAMYOUNG S&C – field-proven in the HVAC and auto industry for over 15 years, HCS2D-3V offers another smart sensing solution for excellent reliability, high accuracy, and cost-effective sensing applications.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Controller for DX Constant Temp & Humidity Unit

https://korean-electronics.com//inquiry[INQ. NO. 2004E02] A high-performance RISC micom integrates operations of various HVAC systems and controls them digitally and precisely. It handles the instructions really fast and reduces the risks with high sample rates. It also provides a digital calibration that suits the requirements of different conditions.
A 5″ LCD of 240X128 resolution supports the multilingual (English, Japanese, Chinese, and Korean language) texts and images for users. Any operator can select from the menus by following the steps on the screen. It is as easy as your fingertips.
Like a Swiss army knife, it is a very small and strong one suitable for multiple purposes. Integrating modules of control and display makes it possible to be compact and reliable. It can be installed almost everywhere, even in small spaces, and can be applied to various HVAC systems (AHU, temperature, humidity, dehumidification, etc.). With the real-time information on the screen and simple operation as well as intelligent multifunctions, operators can handle the situations without problem and save the time, money, and efforts for maintenance.
DX140 records the important data such as trips, and traces up to 160 events. It provides the useful information for analysis and troubleshooting including history while tripped.
Small and reliable power relays are used for output signals. Digital I/O signals are completely insulated to block the signals from outside affecting the mainboard. There are safety functions in CPU. Brownout monitors the control power in real time and watchdog checks the status continuously (every 32 msec), and allows it to recover from CPU down by noise automatically.

Smart Chiller Controller

With super PID control algorithm developed by Dotech’s innovative technologies, the precise ±0.1˚C control based on auto tuning is provided at an unbelievable price. CX9230 transforms your chiller into a smart device.
Dual sensors culminated by Dotech’s temperature control technologies and expertise measure the inlet and outlet temperatures and remove the noise rapidly and elaborately.
Sensored temperatures set according to each proportion enable ideal temperature control. Like the DX Series, CX has a powerful trip data log. Up to 100 events can be traced and operators can handle the situations flexibly and precisely.

Dual-channel analog outputs(4~20mA) are for heating/cooling control and can be applied to computed heating/cooling or condenser fan control. Depending on the requirements and applications, the desired one can be selected from among the specified models.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Ultra-Precision Driver for EEV

https://korean-electronics.com//inquiry[INQ. NO. 2004E01] EVD9 is a high-precision driver for electronic expansion valve that realizes a variety of compatibility and precise control. Users can easily control the electronic expansion valves connecting PLC controllers by using EVD9. Moreover, EVD9 is compatible with almost all stepping motor type EEVs.



Universal Intelligent Controller

BX1600 is a controller suitable for wide applications to cooling and heating units developed by Dotech’s advanced heat pump control technologies. The state-of-the-art defrost control logic linked with electronic expansion valves ensures superior efficiency.
Custom parameter configuration enables the best performance in various environments by changing the functions and features easily on site.

Thermo-Hygrostat Controller

DQ1000 is an electronic control unit equipped with a high-performance RISC microprocessor, which is embedded inside a thermo-hygrostat and controls its operation based on digital processing. As a part of the split system, the display unit has a VFD (LCD) providing operators with information on the status immediately, thus enabling easy control and maintenance.
A high-performance RISC micom integrates operations and controls digitally and precisely. It handles the instructions really fast and reduces the risks with high sample rates.
Digital calibration on user’s demand is supported. DQ1000 has a sleek design of a rail-mounted control module and a slim display. The ergonomic keypad layout and step-by-step mode selection enable users to set the parameters easily.
Digital I/O signals are completely insulated to block the signals from outside affecting the mainboard. There are safety functions in CPU. Brownout monitors the control power in real time and a watchdog checks the status continuously (every 32 msec) and allows it to it recover from CPU down by noise automatically.
Panasonic NAIS relay which is specifically designed for PLC is deployed to prevent noise from output. The Toshiba TLP523 photocoupler also blocks noise into control power from relay power. It is small but can work at 5A, 250VAC max. despite its small size. Relay contact is specially coated and there is no problem in using it for over 100,000 contacts.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Line-Bar Type UV LED Curing System

https://korean-electronics.com//inquiry[INQ. NO. 2003E08] This slim-type UV LED curing system from L-Light Co., Ltd. is a product that exerts its ability in improving the curing quality and increasing the working speed remarkably based on the high-strength UV output and high stability.
As it is designed in an unlimitedly extendable structure in a module unit, an installation optimized for the site condition is possible.
L-Light is a company that constantly strives to apply LED technology to the FA industry. The company has been devoting its efforts to research and development to supply the optimal lighting systems for complex and diverse machine vision devices.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Motion Chips

https://korean-electronics.com//inquiry[INQ. NO. 2003E07] AJINEXTEK’s CAMC Series of motion chips including one axis and four axes motion control chips are the only motion control chips manufactured with pure domestic technology of Ajinextek, and these high performance motion control chips control the pulses required for controlling various motors such as step motor and DC/AC servo motor.



Module Board
AJINEXTEK’s module board products are the add-on module series designed considering optimum design and flexibility of the control system, and can be installed in standard bus base boards such as ISA and PCI, enabling various systems to be built.
AJINEXTEK Co., Ltd. has been concentrating its capabilities through the combined efforts of all its employees in order to advance into the world market by localizing the controller required for the advanced industrial automation field since its establishment in 1995.

As a result, the company developed and sold the motor control only VLSI chip (CAMC-series) solely in Korea, and positioned as a specialty company of parts and materials in Mechatronics.
Based on this, the company has localized various controllers for the semiconductor manufacturing process, LED, LCD display process, PCB / SMT process, mobile and automobile process.

korean-electronics.com | Blog Magazine of korean electronics, brands and Goods

Wire Connector

https://korean-electronics.com//inquiry[INQ. NO. 2003E06] This connector with an ABS push button is for the industrial use whose body is made of polycarbonate featuring shock- and heat-resistance. This is designed to facilitate your work better than terminal block wiring.
This is a DIN rail connector with versatile utilization, as well as a space-saving connector due to its compact size.
SEGIBIZ Co.,Ltd. has been striving to become a leading company in the 21st century since the first exports to Toyota Motor Corporation, Japan in 2006.

SEGIBIZ carries out its research in such a way as to make the rough image of electricity for people to feel familiar. To enhance the product quality and develop new technology, SEGIBIZ also established a corporate R&D center to continue development.
